Strona główna Sklep Kola Vulkollan® wheel, fixed castor with a top plate — TR-63GH-SF-EE-HD

Výrobce: Tellure Rôta

Vulkollan® wheel, fixed castor with a top plate — TR-63GH-SF-EE-HD

1.199,30 zł bez DPH / ks

1.475,14 złbrutto

Rozměr (Ø×šířka)

Ø200×78 mm

Ø250×60 mm

Ø250×78 mm

Ø300×60 mm

Ø300×78 mm

Ložisko

Hub with ball bearings

Deska/výška

175X140

200X160

Kod produktu:

SKU:638416

Cena jednostkowa: 1.199,30 zł netto

Wartość netto (1 szt.) 1.199,30 zł

Podatek VAT (23%) 275,84 zł

Razem brutto 1.475,14 zł

Zobrazit veškeré podrobnosti

The wheel has a Vulkollan® tread and a cast iron centre. This is a fixed castor with a top plate. This version is available in diameters of 200–300 mm, widths of 60–78 mm and load capacities of 1500–2300 daN at 4 km/h.

Manufacturer	Tellure Rôta (distributed by Myzer)
Series	TR-63GH-EEHD
Design	fixed castor / top plate
Tread material	Vulkollan®
Centre material	cast iron

Selection table — item specifications

Code	Ø D (mm)	Width F (mm)	Total height H (mm)	Top plate A×B (mm)	Load capacity at 4 km/h (daN)	Rolling elements	Weight (kg)
638416	200	78	275	175X140	1600	Hub with ball bearings	12.18
638407	250	60	320	175X140	1500	Hub with ball bearings	13.23
638417	250	78	320	175X140	1600	Hub with ball bearings	14.91
638427	250	78	325	200X160	1900	Hub with ball bearings	15.23
638408	300	60	360	175X140	1600	Hub with ball bearings	16.62
638428	300	60	365	200X160	1750	Hub with ball bearings	16.95
638418	300	78	360	175X140	1600	Hub with ball bearings	18.99
638438	300	78	365	200X160	2300	Hub with ball bearings	19.32
