TR polyurethane wheel, fixed castor P with a top plate — TR-65-ALL-CC-SF-P

The wheel has a TR polyurethane tread and an aluminium centre. This is a fixed castor with a top plate. This version is available in diameters of 100–200 mm, widths of 30–50 mm and load capacities of 250–850 daN at 4 km/h.
| Manufacturer | Tellure Rôta (distributed by Myzer) |
| Series | TR-65AL-P-PT |
| Design | fixed castor / top plate |
| Tread material | TR polyurethane |
| Centre material | aluminium |
Selection table — item specifications
| Code | Ø D (mm) | Width F (mm) | Total height H (mm) | Top plate A×B (mm) | Load capacity at 4 km/h (daN) | Rolling elements | Weight (kg) |
|---|---|---|---|---|---|---|---|
| 658602 | 100 | 30 | 138 | 100X85 | 250 | Hub with ball bearings | 0.82 |
| 658603 | 125 | 35 | 161 | 100X85 | 350 | Hub with ball bearings | 0.97 |
| 658604 | 150 | 40 | 200 | 140X110 | 600 | Hub with ball bearings | 2.19 |
| 658614 | 160 | 50 | 205 | 140X110 | 800 | Hub with ball bearings | 2.53 |
| 658606 | 200 | 50 | 250 | 140X110 | 850 | Hub with ball bearings | 2.48 |
