The wheel has a TR polyurethane tread and an aluminium centre. This is a fixed castor with a top plate. The variants of this model cover diameters of 125–200 mm, widths of 40–50 mm and load capacities of 450–800 daN at 4 km/h.
| Manufacturer | Tellure Rôta (distributed by Myzer) |
| Series | TR-65ER-P-PT |
| Configuration | fixed castor / top plate |
| Tread material | high-thickness TR polyurethane |
| Centre material | aluminium |
Selection table — item specifications
| Code | Ø D (mm) | Width F (mm) | Overall height H (mm) | Top plate A×B (mm) | Load capacity at 4 km/h (daN) | Rolling elements | Weight (kg) |
|---|---|---|---|---|---|---|---|
| 656013 | 125 | 40 | 170 | 140X110 | 450 | Hub with ball bearings | 1.63 |
| 656014 | 160 | 50 | 205 | 140X110 | 700 | Hub with ball bearings | 2.28 |
| 656016 | 200 | 50 | 250 | 140X110 | 800 | Hub with ball bearings | 2.68 |
