Strona główna Sklep Kolesá TR polyurethane wheel, swivel castor with a top plate — TR-65HT-SRP-EE-MHD

Výrobca: Tellure Rôta

TR polyurethane wheel, swivel castor with a top plate — TR-65HT-SRP-EE-MHD

552,90 zł bez DPH / ks

680,07 złbrutto

Rozmer (Ø×šírka)

Ø100×40 mm

Ø125×40 mm

Ø180×50 mm

Ø160×50 mm

Ø200×50 mm

Ložisko

Hub with ball bearings

Kod produktu:

Jednotka SKU:655602

Cena jednostkowa: 552,90 zł netto

Wartość netto (1 szt.) 552,90 zł

Podatek VAT (23%) 127,17 zł

Razem brutto 680,07 zł

Zobraziť všetky podrobnosti

The wheel has a TR polyurethane tread and an aluminium centre. This is a swivel castor with a top plate. The variants of this model cover diameters of 100–200 mm, widths of 40–50 mm and load capacities of 350–800 daN at 4 km/h.

Manufacturer	Tellure Rôta (distributed by Myzer)
Series	TR-65HT-EEMHD
Configuration	swivel castor / top plate
Tread material	TR polyurethane
Centre material	aluminium

Selection table — item specifications

Code	Ø D (mm)	Width F (mm)	Overall height H (mm)	Top plate A×B (mm)	Load capacity at 4 km/h (daN)	Rolling elements	Weight (kg)
655602	100	40	170	135X110	350	Hub with ball bearings	3.36
655603	125	40	182	135X110	450	Hub with ball bearings	3.68
655605	180	50	242	135X110	750	Hub with ball bearings	4.56
655614	160	50	215	135X110	700	Hub with ball bearings	4.18
655606	200	50	252	135X110	800	Hub with ball bearings	4.88
