Column barrier 1R Hexagon

Name: Column barrier 1R Hexagon
Brand: Raysan
SKU: RS-1R-COLUMN-BARRIER-HEXAGON
Availability: InStock

Column barrier 1R Hexagon

Product code:

SKU:RS-1R-COLUMN-BARRIER-HEXAGON

Because they can be tailored, specified with many options and supplied in different dimensions, Raysan products are available on request for quotation.

Request a quote

View full details

OTHER PRODUCTS IN THIS COLLECTION

This easy-to-install barrier provides effective protection for large structural columns in areas with heavy transport and loading vehicle traffic. It absorbs impacts from forklifts and other vehicles, preventing damage and preserving the integrity of key infrastructure. Suitable for indoor and outdoor use, it offers long-lasting durability and helps to maintain an organised, safe space.

The advanced polymer is made from a high-quality blend of polyolefins and rubber additives, providing high strength. This composition combines durability with flexibility. The manufacturing process reorients the molecular structure, giving the barrier shape memory. As a result, the barrier fully recovers its shape after impacts, maintaining its performance and reliability.

Benefits

Strength and low weight
Thanks to a specially developed chemical composition, the barrier outperforms steel barriers in terms of strength and low weight. It is considerably lighter while retaining high durability.
Modular design
Thanks to its modular design, the barrier can easily be adapted to the changing needs of your plant. This flexible solution is easy to install, assemble, dismantle, move and reposition.
Corrosion resistance
Unlike steel barriers, barriers made of durable polymer materials are resistant to environmental factors such as sunlight and rainwater.
No painting or maintenance required
Unlike traditional steel barriers, which require regular painting and maintenance, a barrier made of through-coloured material needs neither. Even when scratched by an impact, its surface retains its original colour unchanged.
UV resistance
The barriers are highly resistant to UV radiation. Their chemical structure remains unchanged even after prolonged outdoor use, ensuring long-term durability.
Antibacterial properties
The barriers have a specially developed chemical composition that prevents chemical reactions with the substances they come into contact with.

Specification

Version ZETA

Post size [D1]Ø160 mm

Rail size [D2]100 mm x 100 mm

Maximum height [H]400 mm

Maximum barrier length [L1]Column [ØC] + 670 mm

Maximum barrier length [L2]Column [ØC] + 430 mm

Impact zone [Z]100 mm

Version TETA

Post size [D1]Ø125 mm

Rail size [D2]50 mm x 100 mm

Maximum height [H]400 mm

Maximum barrier length [L1]Column [ØC] + 640 mm

Maximum barrier length [L2]Column [ØC] + 400 mm

Impact zone [Z]100 mm

Standard colours

RAL 1018PANTONE 123C

RAL 9005PANTONE B6C

*The RAL and PANTONE colours given are the closest equivalents to the standard RAYSAN colours, but may not exactly match the actual product colour and are for guidance only.

Additional information

Manufacturer's model1R Column Barrier Hexagon

ApplicationBuilding and equipment protection, Column protection

Intended for (vehicles)Light forklift, Electric stacker, Hand pallet truck

Availabilitymade to order
