Safety barrier 2R XL

Name: Safety barrier 2R XL
Brand: Raysan
SKU: RS-2R-BARRIER-XL
Availability: InStock

Safety barrier 2R XL

Product code:

SKU:RS-2R-BARRIER-XL

Because they can be tailored, specified with many options and supplied in different dimensions, Raysan products are available on request for quotation.

Request a quote

View full details

OTHER PRODUCTS IN THIS COLLECTION

Designed for quick installation, this barrier protects against vehicle impacts at medium height in indoor and outdoor spaces with transport and loading vehicle traffic. It is used to protect structures, goods and machinery in areas exposed to heavy impacts, and also helps to mark out and organise space while remaining durable over the long term. Intended for demanding environments, it ensures reliable performance under repeated impacts.

The advanced polymer is made from a high-quality blend of polyolefins and rubber additives, providing high strength. This composition combines durability with flexibility. The manufacturing process reorients the molecular structure, giving the barrier shape memory. As a result, the barrier fully recovers its shape after impacts, maintaining its performance and reliability.

Benefits

Strength and low weight
Thanks to a specially developed chemical composition, the barrier outperforms steel barriers in terms of strength and low weight. It is considerably lighter while retaining high durability.
Modular design
Thanks to its modular design, the barrier can easily be adapted to the changing needs of your plant. This flexible solution is easy to install, assemble, dismantle, move and reposition.
Corrosion resistance
Unlike steel barriers, barriers made of durable polymer materials are resistant to environmental factors such as sunlight and rainwater.
No painting or maintenance required
Unlike traditional steel barriers, which require regular painting and maintenance, a barrier made of through-coloured material needs neither. Even when scratched by an impact, its surface retains its original colour unchanged.
UV resistance
The barriers are highly resistant to UV radiation. Their chemical structure remains unchanged even after prolonged outdoor use, ensuring long-term durability.
Antibacterial properties
The barriers have a specially developed chemical composition that prevents chemical reactions with the substances they come into contact with.

Specification

Version ZETA

Post dimension [D1]Ø160 mm

Post height [H]720 mm

Rail dimension [D2]Ø250 mm

Rail length range [L1]1000 mm – 2960 mm

Maximum barrier length [L2]2960 mm

Impact zone [Z]570 mm

Version TETA

Post dimension [D1]Ø125 mm

Post height [H]540 mm

Rail dimension [D2]Ø160 mm

Rail length range [L1]1000 mm – 2925 mm

Maximum barrier length [L2]2925 mm

Impact zone [Z]390 mm

Impact energy (90°)

ZETA23 100 J

TETA14 800 J

*90° impact at the centre of the rail at maximum post centre spacing

*Results reflect instantaneous impact values

*Does not provide resistance to impacts from sharp objects

Standard colours

RAL 1018PANTONE 123C

RAL 9005PANTONE B6C

*The RAL and PANTONE colours given are the closest equivalents to the standard RAYSAN colours, but may not exactly match the actual colour of the product and are for guidance only.

Additional information

Manufacturer's model2R Barrier XL

ApplicationBuilding and equipment protection, Corridor and wall protection, Machine protection

Suitable for (vehicles)Light forklift, Electric stacker, Hand pallet truck

Availabilitymade to order
