TR polyurethane wheel, fixed castor with a top plate — TR-64-SF-EE-HD

863,34 zł net / pc

1.061,91 złbrutto

Dimensions (Ø×width)

Ø150×78 mm

Ø200×78 mm

Ø250×60 mm

Ø250×78 mm

Ø300×60 mm

Ø300×78 mm

Rolling elements

Hub with ball bearings

Top plate/height

175X140

200X160

Product code:

SKU:648415

Unit price: 863,34 zł netto

Net value (1 pcs) 863,34 zł

VAT (23%) 198,57 zł

Total gross 1.061,91 zł

View full details

The wheel has a TR polyurethane tread and a cast iron centre. This is a fixed castor with a top plate. The variants of this model cover diameters of 150–300 mm, widths of 60–78 mm and load capacities of 1000–2300 daN at 4 km/h.

Manufacturer	Tellure Rôta (distributed by Myzer)
Series	TR-64-EEHD
Configuration	fixed castor / top plate
Tread material	TR polyurethane
Centre material	cast iron

Selection table — item specifications

Code	Ø D (mm)	Width F (mm)	Overall height H (mm)	Top plate A×B (mm)	Load capacity at 4 km/h (daN)	Rolling elements	Weight (kg)
648415	150	78	218	175X140	1000	Hub with ball bearings	10.61
648424	150	78	223	200X160	1000	Hub with ball bearings	10.61
648416	200	78	275	175X140	1600	Hub with ball bearings	12.18
648407	250	60	320	175X140	1500	Hub with ball bearings	13.23
648417	250	78	320	175X140	1600	Hub with ball bearings	14.91
648427	250	78	325	200X160	1900	Hub with ball bearings	15.23
648408	300	60	360	175X140	1600	Hub with ball bearings	16.62
648428	300	60	365	200X160	1750	Hub with ball bearings	16.95
648418	300	78	360	175X140	1600	Hub with ball bearings	18.99
648438	300	78	365	200X160	2300	Hub with ball bearings	19.32
