ESD TR polyurethane wheel, fixed castor (NL-M) with a top plate — TR-65ESD-SF-NL

154,05 zł net / pc

189,48 złbrutto

Dimensions (Ø×width)

Ø80×25 mm

Ø100×30 mm

Ø125×35 mm

Ø150×40 mm

Ø160×50 mm

Ø200×50 mm

Rolling elements

Hub with ball bearings

Product code:

SKU:658201ESD

Unit price: 154,05 zł netto

Net value (1 pcs) 154,05 zł

VAT (23%) 35,43 zł

Total gross 189,48 zł

View full details

The wheel has an ESD TR polyurethane tread and an aluminium centre. This is a fixed castor with a top plate. The variants of this model cover diameters of 80–200 mm, widths of 25–50 mm and load capacities of 170–500 daN at 4 km/h.

Manufacturer	Tellure Rôta (distributed by Myzer)
Series	TR-65ESD-NL-M
Design	fixed castor / top plate
Tread material	ESD TR polyurethane
Centre material	aluminium

Selection table — item specifications

Code	Ø D (mm)	Width F (mm)	Total height H (mm)	Top plate A×B (mm)	Load capacity at 4 km/h (daN)	Rolling elements	Weight (kg)
658201ESD	80	25	107	100X85	170	Hub with ball bearings	0.52
658202ESD	100	30	128	100X85	200	Hub with ball bearings	0.69
658203ESD	125	35	156	100X85	220	Hub with ball bearings	0.89
658104ESD	150	40	194	140X110	480	Hub with ball bearings	-
658114ESD	160	50	198	140X110	500	Hub with ball bearings	2.38
658106ESD	200	50	240	140X110	500	Hub with ball bearings	2.76
