Strona główna Sklep Roues TR-Roll polyurethane wheel, fixed castor P with a top plate — TR-62BS-SF-P

Fabricant : Tellure Rôta

TR-Roll polyurethane wheel, fixed castor P with a top plate — TR-62BS-SF-P

171,82 zł HT / pce

211,34 złbrutto

Dimensions (Ø×largeur)

Ø100×30 mm

Ø125×35 mm

Ø150×40 mm

Ø160×50 mm

Ø200×50 mm

Roulement

Hub with ball bearings

Kod produktu:

SKU:628542

Cena jednostkowa: 171,82 zł netto

Wartość netto (1 szt.) 171,82 zł

Podatek VAT (23%) 39,52 zł

Razem brutto 211,34 zł

Afficher tous les détails

The wheel has a TR-Roll polyurethane tread and an aluminium centre. This is a fixed castor with a top plate. This version is available in diameters of 100–200 mm, widths of 30–50 mm and load capacities of 200–700 daN at 4 km/h.

Manufacturer	Tellure Rôta (distributed by Myzer)
Series	TR-62BS-P
Design	fixed castor / top plate
Tread material	TR-Roll polyurethane
Centre material	aluminium

Selection table — item specifications

Code	Ø D (mm)	Width F (mm)	Total height H (mm)	Top plate A×B (mm)	Load capacity at 4 km/h (daN)	Rolling elements	Weight (kg)
628542	100	30	138	100X85	200	Hub with ball bearings	0.78
628543	125	35	161	100X85	250	Hub with ball bearings	0.98
628544	150	40	200	140X110	450	Hub with ball bearings	2.19
628550	160	50	205	140X110	550	Hub with ball bearings	2.53
628546	200	50	250	140X110	700	Hub with ball bearings	2.48
