Strona główna Sklep Roues TR polyurethane wheel, swivel castor with a top plate — TR-64-SRP-EE-HD

Fabricant : Tellure Rôta

TR polyurethane wheel, swivel castor with a top plate — TR-64-SRP-EE-HD

1.243,21 zł HT / pce

1.529,15 złbrutto

Dimensions (Ø×largeur)

Ø150×78 mm

Ø200×78 mm

Ø250×60 mm

Ø250×78 mm

Ø300×60 mm

Ø300×78 mm

Roulement

Hub with ball bearings

Platine/hauteur

175X140

200X160

Kod produktu:

SKU:648315

Cena jednostkowa: 1.243,21 zł netto

Wartość netto (1 szt.) 1.243,21 zł

Podatek VAT (23%) 285,94 zł

Razem brutto 1.529,15 zł

Afficher tous les détails

The wheel has a TR polyurethane tread and a cast iron centre. This is a swivel castor with a top plate. The variants of this model cover diameters of 150–300 mm, widths of 60–78 mm and load capacities of 1000–2300 daN at 4 km/h.

Manufacturer	Tellure Rôta (distributed by Myzer)
Series	TR-64-EEHD
Configuration	swivel castor / top plate
Tread material	TR polyurethane
Centre material	cast iron

Selection table — item specifications

Code	Ø D (mm)	Width F (mm)	Overall height H (mm)	Top plate A×B (mm)	Load capacity at 4 km/h (daN)	Rolling elements	Weight (kg)
648315	150	78	218	175X140	1000	Hub with ball bearings	12.15
648324	150	78	223	200X160	1000	Hub with ball bearings	12.15
648316	200	78	275	175X140	1600	Hub with ball bearings	13.72
648307	250	60	320	175X140	1500	Hub with ball bearings	14.82
648317	250	78	320	175X140	1600	Hub with ball bearings	16.5
648327	250	78	325	200X160	1900	Hub with ball bearings	17.56
648308	300	60	360	175X140	1600	Hub with ball bearings	18.24
648328	300	60	365	200X160	1750	Hub with ball bearings	19.3
648318	300	78	360	175X140	1600	Hub with ball bearings	20.61
648338	300	78	365	200X160	2300	Hub with ball bearings	21.67
