TR polyurethane wheel, swivel castor (EP) with a top plate

Strona główna Sklep Roues TR polyurethane wheel, swivel castor (EP) with a top plate — TR-64-SRP-EP

The wheel has a TR polyurethane tread and a cast iron centre. This is a swivel castor with a top plate. The variants of this model cover diameters of 100–250 mm, widths of 38–78 mm and load capacities of 350–1600 daN at 4 km/h.

Manufacturer	Tellure Rôta (distributed by Myzer)
Series	TR-64-EP
Configuration	swivel castor / top plate
Tread material	TR polyurethane
Centre material	cast iron

Selection table — item specifications

Code	Ø D (mm)	Width F (mm)	Overall height H (mm)	Top plate A×B (mm)	Load capacity at 4 km/h (daN)	Rolling elements	Weight (kg)
647852	100	38	140	100X85	350	Hub with ball bearings	2.15
647853	125	38	164	100X85	350	Hub with ball bearings	2.64
647863	125	50	188	135X110	550	Hub with ball bearings	4.61
647854	150	50	200	135X110	750	Hub with ball bearings	5.04
647824	150	58	200	135X110	850	Hub with ball bearings	5.44
647864	160	50	205	135X110	750	Hub with ball bearings	5.16
647855	180	50	228	135X110	900	Hub with ball bearings	5.6
647856	200	50	250	135X110	1000	Hub with ball bearings	6.35
647866	200	78	275	175X140	1600	Hub with ball bearings	12.3
647857	250	60	300	175X140	1500	Hub with ball bearings	13.16
