The wheel has a TR polyurethane tread and an aluminium centre. This is a swivel castor with a top plate. The variants of this model cover diameters of 160–200 mm, widths of 50 mm and load capacities of 500 daN at 4 km/h.
| Manufacturer | Tellure Rôta (distributed by Myzer) |
| Series | TR-65ER-M |
| Configuration | swivel castor / top plate |
| Tread material | high-thickness TR polyurethane |
| Centre material | aluminium |
Selection table — item specifications
| Code | Ø D (mm) | Width F (mm) | Overall height H (mm) | Top plate A×B (mm) | Load capacity at 4 km/h (daN) | Rolling elements | Weight (kg) |
|---|---|---|---|---|---|---|---|
| 655904 | 160 | 50 | 199 | 140X110 | 500 | Hub with ball bearings | 2.81 |
| 655906 | 200 | 50 | 240 | 140X110 | 500 | Hub with ball bearings | 3.52 |
