Thermoplastic rubber wheel, fixed castor NL with a top plate — TR-71CC-SF-NL

47,23 zł HT / pce

58,09 złbrutto

Dimensions (Ø×largeur)

Ø80×30 mm

Ø100×30 mm

Ø125×35 mm

Ø150×45 mm

Ø160×50 mm

Ø200×50 mm

Roulement

Hub with ball bearings

Kod produktu:

SKU:714801

Cena jednostkowa: 47,23 zł netto

Wartość netto (1 szt.) 47,23 zł

Podatek VAT (23%) 10,86 zł

Razem brutto 58,09 zł

Afficher tous les détails

The wheel has a thermoplastic rubber tread and a polypropylene centre. This is a fixed castor with a top plate. Variants of this version cover diameters of 80–200 mm, widths of 30–50 mm and load capacities of 70–225 daN at 4 km/h.

Manufacturer	Tellure Rôta (distributed by Myzer)
Series	TR-71CC-NL
Configuration	fixed castor / top plate
Tread material	non-marking thermoplastic rubber
Centre material	polypropylene

Selection table — item specifications

Code	Ø D (mm)	Width F (mm)	Height H (mm)	Plate A×B (mm)	Load capacity at 4 km/h (daN)	Rolling elements	Weight (kg)
714801	80	30	107	100X85	70	Hub with ball bearings	0.45
714802	100	30	128	100X85	100	Hub with ball bearings	0.5
714803	125	35	156	100X85	120	Hub with ball bearings	0.61
714811	150	45	194	140X110	180	Hub with ball bearings	1.68
714810	160	50	199	140X110	200	Hub with ball bearings	1.77
714806	200	50	240	140X110	225	Hub with ball bearings	2.13
